  LOW ORDER WAVEPLATES
View Original Picture
Click to see more pictures of products:
   Details

Introduction:
Multiple Order waveplates(Low Order Waveplate) are made so that the relative phase change is larger than the required value by an integer multiple of 2π. While the performance at the design wavelength can be essentially the same, chromatic dispersion has a stronger effect for thicker plates, so that the optical bandwidth in which the plate has roughly the correct relative phase change is limited. Also, the retardance has a higher temperature sensitivity.

Main applicationsLaser systems,Spectrophotometry,Optical communication devices,DVD, CD, Polarization digital cameras

DELICATE supply products with:


Matereial:  Crystal Quartz
Dimension Tolerance:   +0.0,-0.2mm
Wavefront Distortion:   λ/10 @ 632.8 nm
Surface Quality:   40-20
Retardation Tolerance:    <λ/500

Parallelism:   ≤1 arc second
Wavelength Range:   350-2100nm
Coating:   R<0.2% on both surface at central wavelength
